Cincinnati 230-Ton x 14' Hydraulic Press Brake Model: 230CB12

Cincinnati 230-Ton x 14' Hydraulic Press Brake Model: 230CB12

Contact us for price

Location:Toledo, OH

orCall 419-350-2986

Description

Cincinnati 230-Ton x 14' Hydraulic Press Brake

Model: 230CB12

YEAR NEW ......................... 1980

CAPACITY ......................... 230 TON

OVERALL LENGTH OF BED AND RAM .... 14'

DISTANCE BETWEEN HOUSING ......... 12'6"

STROKE OF RAM .................... 10"

OPEN HEIGHT ...................... 17"

CLOSED HEIGHT .................... 7"

DEPTH OF THROAT .................. 8"

RAM SPEED HIGH ................... 101 IPM

RAM SPEED MEDIUM ................. 49 IPM

RAM SPEEDS LOW ................... 14 IPM

RAM SPEEDS RETURN ................ 95 IPM

HURCO AUTOBEND 20C CNC BACK GAUGE. YES

MILLED & DRILL FOR ANGLES ........ YES

ELECTRIC FOOT TRIP ............... YES

MOTOR ............................ 30 HORSEPOWER

Specifications

ManufacturerCincinnati 230-Ton x 14' Hydraulic Press Brake Model:
Model230CB12
ConditionUsed
Stock Number0307400
