2019 Bystronic Bysprint 3015 6000-Watt Fiber Laser w/Unloading System

Sold

2019 Bystronic Bysprint 3015 6000-Watt Fiber Laser w/Unloading System

Location:Toledo, OH

Description

6000-Watt Bystronic Bysprint 3015 Fiber Laser w/Unloading System

Mfg: Bystronic

Model: Bysprint 3015

YOM: 2019

Wattage: 6000 W

 Specifications:

Nominal sheet size:

X: 120"

Y: 60"

Cutting area:

X: 120"

Y: 60"

Z: 2.75"

Maximum Positioning Speed Parallel Axis X, Y: 3937 IPM

Maximum Simultaneous Positioning Speed 5511 IPM

Positioning Accuracy Pa* +/- 0.004"

Repeatability Ps* +/- 0.002"

Maximum Workpiece weight: 1962 lbs

Machine Weight** 26,455 lbs

Operation Via Panel: ByVision Touchscreen and Manual Control Unit

Power 6000W

Control Range 600-6000W

Wavelength Fiber

Maximum Sheet Thickness:

Steel 1", Stainless Steel 1.18", Aluminum 1.18", Brass 0.59", Copper 0.47"

All Specifications Subject to Buyer Verification


Specifications

ManufacturerBystronic
ModelBysprint 3015 6000-Watt Fiber Laser w/Unloading System
Year2019
ConditionUsed
Stock Number0307293
